Zhuoli

PTFE-SG

Product description

PTFE-SG chemical hos is recommended for delivery and / or aspiration of a great variety of chemical products that do not have a good behavior with PP such as some types of acids and solvents such as Toluene found in non-corrosive environment. It is suitable for use in loading and unloading of tank trucks, wagons, in plants and Marine applications
Contact now

Product Details


Description

PTFE-SG chemical hose is used for conveying and/or suction of various highly corrosive materials compatible with PTFE and stainless steel, such as low concentrations of phosphoric acid, naphtha, or nitric acid. It is suitable for loading and unloading in applications such as oil tankers, trucks, and factories.



Construction

Inner Wire spiral: Stainless Steel 304/316L (S)

Outer Wire spiral: Galvanized Steel (G)

Inner Lining: PTFE

Cover: PVC Coated Polyester Cloth



Features

Size: 1” to 12”

Norms: EN 13765:2010 /CCS

Temperature range: -30℃ +80℃

Safety factor: 5:1

Vacuum: 0.9 bar

Max. Length : 30 m.
